Description
Why use Apiezon Waxes? Versatile products suitable for a multitude of uses Etch resist (Wax W only) First-rate vapor pressure characteristics High purity combined with powerful gettering & clean meltdown properties Excellent waterproof media Easy to use and to remove 10 year shelf life Applications Apiezon Wax W: Hard Vacuum Sealing / Mounting Wax, Etch Resist Apiezon Wax W100: Medium Hardness Vacuum Sealant / Mounting Wax Apiezon Wax W40: Soft Vacuum Sealant / Mounting Wax Apiezon Q Compound: Vacuum Sealing Compound Apiezon Q Compound Apiezon Q Compound is an effective temporary vacuum sealant that is used as a short term solution in situations which do not allow for the immediate dismantling of a system for repair. Why use Apiezon Q Compound? Temporary vacuum sealant Versatile product suitable for a multitude of uses Excellent waterproof medium Easy to use and to remove 10 year shelf life
| Typical Property | Wax X | Wax W100 | Wax W40 | Q Compound |
| Approximate Softening Point °C °F | 80-90 176-194 | 50-60 122-140 | 40-50 104-122 | 40-50 104-122 |
| Estimated Vapor Pressure @ 20°C / 68°F, torr | 4.5 x 10-9 | 4.5 x 10-9 | 6 x 10-8 | 1 x 10-4 |
| Temperature of Application °C °F | 130 266 | 110 230 | 90 194 | Ambient |
| Working Temperature Range | -10-75 14-168 | -10-45 14-113 | -10-35 14-95 | -10-30 14-86 |
| Water Permeability g/cm/hr/mm Hg @ 25°C | 0.8 x 10-8 | 1.6 x 10-8 | 1.6 x 10-8 | N/A |
| Pack | N/A |
250 g tin N/A |
250 g tin N/A |
1 Kg N/A |
| Thermal/Electrical Properties Thermal Conductivity @ 20°C, w/m °C | 0.189 | 0.170 | 0.177 | N/A |
| Specific Heat @ 25°C, J/g | 1.8 | 2.7 | 2.9 | N/A |
| Lost Tangent | 0.015 | 0.016 | 0.015 | N/A |
| Permittivity | 2.8 | 2.7 | 2.9 | N/A |
| Volume Resistivity, Ω cm | 6.31 x 10-15 | 1.64 x 10-15 | 5.06 x 10-15 | N/A |
